Interior Commercial Folding Movable Wooden Partition Wall Panel Width 1230 mm
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm sliding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 80 - 120 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Open Style: | Sliding | Product Name: | Sliding Partition Walls |
|---|---|---|---|
| Feature: | Sound Proofing | Size: | 85 Mm |
| Color: | Accept Customized | Application: | Office,hotel,school |
| Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
| Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
| Width: | 85 Mm(3 1/4 Inch) | ||
| Highlight: | acoustic sliding partition,sound proof sliding partitions |
||
Product Description
Interior Commercial Folding Movable Wooden Sliding Partition Walls
Sliding partition walls description:
There are many types of materials used to sliding partition walls. They mainly use melamine board as raw material, and they are also the most active partitions used in the office environment. Because the partitions of such activities are conducive to decoration and design requirements, they mainly introduce melamine here. Plate material active partition feature.
The sldiing partition walls of melamine board is mainly made of double-layered solid material. Its thickness specifications are 65mm, 85mm, 100mm. The frame adopts the qualified aluminum material of the national standard. The choices on are more varied and can be alumina itself. , white or silver gray, can also be freely sprayed according to need, Class A national fire safety standards, noise coefficient range: 37db-53 db.
The use of sliding partition wall is to highlight the overall function of the space area with the overall tone, using a simple and easy assembly method, so that the regional function between space and space increase and clear, throughout the space while highlighting the space Penalization, to show the overall pattern beauty of the overall spatial area.
Sound insulation details about the sliding partition walls
1. Horizontal sound insulation
In order to achieve the best sound insulation, two layers of sound-absorbing rubber structure are used. Using the jack principle, the double rubber strip is pressed against the ceiling track and floor to provide a high stability of the active partition.
2. Corner sound insulation
The use of specially shaped rubber-like corner elements solves the technical problems of handling corner seals; at the same time, superior stability and sound insulation are achieved.
3. Vertical sound insulation
All the soundproof walls are made of highly elastic vertical contact side, concave and convex groove close fitting principle, to ensure the best closure and sound insulation.
4. Skeleton
In view of the hanging structure of the wall plate, it can be freely shaken, and the metal hoop elements between the wall plates are closely combined, effectively blocking the sound transmission. Panels can be replaced as needed for interior design without damaging the entire panel.
5. Sound insulation material
The skeleton is filled with additional sound insulation materials to achieve different sound insulation requirements.
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
The sliding partition walls feature:
(1) The sliding partition walls surface can be made of any decorative surface, perfectly combined with the interior decoration style;
(2) The sliding partition walls are free to move freely and promote flexibility, which can be hidden in special storage cabinets without affecting the overall appearance;
(3) It can be used in conference rooms, exhibition halls, restaurants, training rooms, muti-function halls and other commercial establishments;
(4) Each screen is equipped with a telescopic mechanism,which can serve as a fixed screen and achieve soundproofing;
(5) According to different seating rates, large space can be divided into small spaces to reduce air conditioning power consumption;
(6)It is made of high-efficiency flame-retardant material and has good fireproof performance.
