Commercial Movable Aluminum Office Sliding Partition Walls With Smooth Arc-Shaped Frame
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm sliding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 80 - 120 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Open Style: | Sliding | Product Name: | Sliding Partition Walls |
|---|---|---|---|
| Feature: | Sound Proofing | Size: | 85 Mm |
| Color: | Accept Customized | Application: | Office,hotel,school |
| Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
| Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
| Width: | 85 Mm(3 1/4 Inch) | ||
| Highlight: | acoustic sliding partition,sound proof sliding partitions |
||
Product Description
Commercial Movable Aluminum Office Sound Proofing Sliding Partition Walls
Sliidng partition walls features
1. Any space can be separated along the track, smoothly passing through various turning points, flexible use of space.
2. Rugged aluminum outer frame, with fire-resistant and sound-proof materials, making it more fireproof and soundproof
3. Complete range of sliding partition walls types, suitable for different requirements
4. Forced by the ceiling suspension system when the sliding partition wall is moving, the ground is no longer laid on the ground rail, and the lightness is promoted without noise
5. When the sliidng partition wall is combined in the vertical and horizontal directions, it has fully considered blocking the sound wave propagation path and uses a soft sealing material to make the sound insulation performance more prominent.
6. Hidden handle operating mechanism, smooth arc-shaped frame, simple and reliable mechanical seal device, so that its overall quality sublimation
7. According to the needs of the place, a small door can be added to the mother board to improve the space utilization efficiency. The small door is equipped with an automatic sealing mechanism, which also prevents the sound from being transmitted.
How to install the sliidng partition walls
1. After the sliding partition walls rail is transported to the construction site, the construction personnel should first understand the general decoration style of the site, including the shape of the ceiling, the ground modelling, and whether there is a foot line on the wall, etc., communicate with the woodwork on the spot, and then determine the track installation. position;
2. After the horizontal line is laid down, determine the layout of the air-conditioning duct and fire control pipe, etc. with the construction party to facilitate the determination of the steel structure installation form. It is straight-pull or diagonal support or U-slot fixed, these are responsible installation teams should Do the pre-construction preparations, or else work hastily, affect the on-site construction layout at the time, but also to redo the work, seriously affecting the progress of the construction, but also bring unnecessary trouble to Party A;
3. After the rails are installed, inspect the track horizontally again, and finally perform rust-proof treatment on the steel structure. Then notify Party A to check and explain clearly the position of the track's movable mouth. When clearly indicating the ceiling of the ceiling, the track cannot be fixed with this section, otherwise loading and unloading. The door panel will likely destroy the integrity of the ceiling.
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Acoustic room dividers advantage:
1.With more economy and higher decorative, beautiful and safe, will not scratch the skin.
2.Installation does not affect the construction of smallpox and the ground.
3.Optional with a variety of occasions partition wall, can be customized according to customer requirements.
4.In the re-assembly can make full use of building materials.
5.Selection of high-quality melamine particleboard, sound insulation and sealing a good variety of accessories a variety of options.
