Conference Room Sound Proof Operable Partition Walls Fabric Finished Color Customized
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm acoustic partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 78 - 120 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Width: | 85 Mm(3 1/4 Inch) | Finish: | Fabric |
|---|---|---|---|
| Colors: | Accept Customized | Open Style: | Sliding |
| Feature: | Sound Proofing | Surface: | Melamine,leather,fabric,plywood |
| Application: | Conference Room,Office | Panel Width: | 500 Mm--1230 Mm |
| Product Name: | Acoustic Partition Walls | ||
| Highlight: | acoustic operable partitions,movable acoustic partition walls |
||
Product Description
Conference Room Sound Proof And Acoustic Operable Partition Walls
About BUNGE Acoustic Partition Walls
FACTORY TO CUSTOMER
We have more than 10 years of experience proffession teams in the flexible space management. 3000+ m²factory, can ensure the delivery time no delay. Factory service directly will cut off the additional cost and get good price.
QUALITY GUARANTEE
Besides the professional talent and advanced technology,there are 3 professionals who reponsible for quality inspection.Before delivering the partition walls,they will check all of the production line for 3 times.
INTERNATIONAL COOPERATION
BUNGE factory have more than 10 years experience in cooperating with the designers from all over the world.We often communicate and learn from each other, and they are vey satisfied with our planning for the partition walls.
INSTALLATION SUPERVISE
Besides the installation drawing and video, we have 18 engineers to supervise and install all over the word,ensure you can install the partition wall system smoothly and quickly.
Specifications of Acoustic Movable Partition Walls System
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9mm | 9mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Advantages of Acoustic Partition Walls
- High Soundproof and High Quality
The Rw for acoustic insulation (acoustic rating from 32dB to 55dB) is a fundamental aspect of movable sound-insulated walls and partitions. Bunge products are manufactured in accordance with strict construction and testing criteria to give a high level of quality. (These characteristics also apply to our special products like access doors that are fitted within wall systems. Furthermore, each individual project is given special attention at the design stage so that the requested sound-insulation is always attained. )
- Easy to Operate
Movable systems have the characteristic of being very easy to maneuver and position. This is the result of the high quality, long-lasting components. The panels have a tongue-and-grove profile designed to obtain a perfect visual, geometric and sound-insulation continuity solution. An extendable pressure seal element is located at the top and bottom of each panel that provide sealing and panel stability to the floor and ceiling. Access doors, which are available in different sizes, are inserted in the panels and do not exceed the thickness of the wall system. Doors can be single of double leaf. The locking and releasing of the panels is done in an easy and rapid manner by means of a removable handle that operates a mechanical system. Panels are also easily slid on the overhead guide and this is guaranteed by a reliable mono or bi-track device and also because all systems have no floor guide. Panel storage is also extremely simple and can be designed to be hardly visible and various configurations are possible.
- Design and Technology
Design and technology are the essentials of a successful alliance of partition. The transformation of a large hall into two or more sound-insulated areas which perfectly respond to the requirements of the designer and the needs of the final user without sacrificing style and functionality, can all be achieved by means of Bunge movable sound-insulated walls. In view of the wide choice of finish available, Bunge movable walls can be personalized according to the individual whim or requirement.
- Widely application
The operable wall series is used wherever room space needs to be fully utilized. Hotels, conference centers, multi-function rooms, banquet halls, offices, training areas, etc. can all benefit from the flexibility of Bunge movable operable walls.
