2000mm Height Acoustic Operable Partition Walls For Conference Room
Product Details:
| Place of Origin: | Guangzhou,China |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm acoustic partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ |
|---|---|
| Price: | US $ 78-125 per square meter |
| Packaging Details: | Wooden boxes |
| Delivery Time: | 7-15 days |
| Payment Terms: | T/T |
| Supply Ability: | 5000 square meter per month |
|
Detail Information |
|||
| Feature: | Soundproof | Material: | MDF+Aluminum |
|---|---|---|---|
| Application: | Conference Room,offices | Product Name: | Acoustic Partition Walls |
| Height: | 2000-16000 Mm | Thickness: | 85 Mm(3 1/4 Inch) |
| Highlight: | acoustic operable wall,movable acoustic partition walls |
||
Product Description
Aluminum Sliding Tracks System Acoustic Operable Partition Wall for Conference Rooms
FAQ
How to select the suitable acoustic partition walls for your site?
We have 4 types of acoustic partition walls , 65type , 85type , 100type and 125 ultra-high type . You can choose the right movable wall upon the Height and Soundproof requirement as following:
65type-- Max height 3.5m, soundproof: 38dB to 43dB
85 type— Max height:5.5m,Soundproof: 43dB to 53dB
100type--- Max height:7m,Soundproof: 43dB to 58dB
125ultra-height---Max height:17m,Soundproof : 38dB to 48dB
What you should do on site ?
A beam(truss) should built on site for track installation . The min distance leaving for track installation from false ceiling to top ceiling is 200mm .
How to install ?
We will provide the installation manual and video guiding the installation job . We can also dispatch the installation engineer supervising the installation as request .
What is lead time ?
The lead time is 7 days to 10 days .
How to transport ?
Sea transport is a common mode of transportation. In an emergency, can be air freight.
How do the goods packing ?
Corrugating paper packaging, MDF batten cover all around corner .
The movable wall panel and track, fittings will be packed separately .
What is Procurement procedure ?
Firstly , send us the shop drawings(if the shop drawings is not available , you can tell us the height from false ceiling to finished floor and width from wall to wall)
Secondly , we offer you the movable wall layout drawings for your confirmation
Thirdly , we quote the movable wall in accordance with confirmed drawings .
What is finishing face?
The bottom panel is MDF or plywood , which is unfinished face . You can do decoration on site , such as wallpaper , paint , etc.
We can also provide the product with finished face , such as faux wood , Woven fabric and Leather.
Acoustic Partition Walls Components
Tracks: Made of good quality anodized aluminium 6063-T5 materials, hanging the movable walls panels with wheels.
Wheels/Rollers: It is the carrier for the movable walls, let the panels move more flexibly. Pulley bearing is more than 1600 KGS.
Connectors: Made of anodized aluminium 6063-T5 aluminum tracks, “L”, “T”, “＋”types are available.
Rubber/vinyl seal: Made of Nitrile Butadiene Rubber(NBR+PVC),durable and perfect for sound insulation, wear-resistant.
Rock Wool: Density of 50kg/m3, help us reduce the noise and heat.
Handle: Operate the retractable being up and down.
Retractable mechanism: Control the movement of the top and bottom seal to form a excellent sound insulation performance.
Magnetic Strip: Ferrite plastic magnetic material will be used in between aluminum profiles to enhance acoustic performance of the movable walls.
MDF board: 9 mm thickness, density of 760kg/m3, absorbent thickness expansion rate is less than 15%. Formaldehyde emission is 34mg/100g.
Technical Details
| Panel Width | 500 - 1230mm |
| Panel height | 2000 - 4000mm |
| Sound proof | 32 - 38db |
| Operation | Manual |
| Frame | Aluminum |
| Vertical profile | Anodised aluminum profiles with integrated magnetic strip and sealing edges on the inside |
| Finish options | Fabric, veneer, HPL melamine, vinyl, carpet, customers own material, Bare finish |
| Base options | Plywood, Gypsum, steel, MDF |
| Max width | Unlimited |
| Panel weight | 25 – 40 kg / sq |
| door | Single or double door |
| Top | Manual |
| bottom | Manual |
