Aluminum Alloy Profile Rooms Divider Folding Room Partitions For Office Operable Wall USA
Product Details:
Place of Origin: | Guangzhou, China |
Brand Name: | EBUNGE |
Model Number: | 65 MM |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 square meter |
---|---|
Price: | Negotiable |
Packaging Details: | Carton paper packing ,MDF Batten cover all over the corner |
Delivery Time: | 7-28 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 10000 square meters per month |
Detail Information |
|||
Product Name: | Folding Partition Walls | Material: | MDF |
---|---|---|---|
Color: | Customized | MOQ: | NO MOQ |
Finish: | Melamine;fabric;leather | Package: | Standard Wooden Case |
Function: | Soundproof Partition Wall Panels | Frame Material: | Aluminum Alloy Profile |
Height: | 4000 MM | ||
Highlight: | acoustic folding partition,folding room partitions |
Product Description
Folding Partitions Wall Rooms Divider Folding Room Partitions Office Partitions Operable Wall USA
Product description
Series | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | Top hung only | Top hung only |
Track system | Single or twin point | Single or twin point | Single or twin point |
Panel thickness | 65mm | 80mm / 85mm | 100mm |
Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
Max height | 4000mm | 6000mm | 18000mm |
Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
Face material | 9mm | 9mm / 12mm | 12mm |
Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
The operable wall series is the highest specification range of fully operable, individual-panel partition system. Acoustic insulation of up to 55 db noise reduction is achieved with a combination of operable top and bottom seals, high performance multiple infills and a panel assembly design that allows an acoustic break between the frame and outer layer. The vertical channels of each panel incorporate polymer inserts that facilitate an acoustic seal when the panels are set out as a wall.
The EBUNGE movable partition wall has the following characteristics
1. No rail suspension: the floor has no track, just install the track on the ceiling;
2. Stable and safe: stable and reliable after partitioning, not easy to swing;
3. Compartment environmental protection: the effect of the compartment is good,
the maximum sound insulation coefficient can reach 50db;
4. Insulation and energy saving: excellent thermal insulation performance, according
to different occupancy rates, the hall is divided into small spaces to reduce
air conditioning power consumption;
5. Efficient fire prevention: It is made of high-efficiency fireproof material
and has good fireproof performance;
6. Beautiful and generous: the surface is arbitrarily decorated,
and can be combined with the interior decoration effect;
7. Retractable and flexible: the partition is freely retractable and flexible,
and one person can complete the whole process of partitioning;
8. Convenient collection: When closing the board, the partition can be hidden
in the special storage cabinet, which does not affect the overall appearance;
9. Wide range of applications: products used in hotels, hotels, restaurants,
conference halls, exhibition halls, high clean factories and offices.
EBUNGE movable partition walls have unparalleled quality, design flexibility, acoustic performance and lasting durability. Proudly manufactured in the Guangzhou, EBUNGE movable partition walls with aluminum frame have the most widespread application. The partition is constituted by a set of flat panel whose width ranges from 700mm to 1200mm. The panel is provided with various specifications and characteristics to satisfy most requirements of design and budget . Its thickness can be 65mm,80mm or 100mm. Additionally, each model comes with different grades of sound insulation as well as single or paired hinges. EBUNGE movable partition walls can be designed with the industry's most comprehensive range of dimensions, performance options, and decorative finishes. Increasingly, efficient space utilization becoming a must for offices, hotels, exhibition centers, studios and so on.
Removable office wall partitions is a hanging system, which only have the ceiling rails, but there is nothing on the floor, so it will not damage the carpet or floor at site. Removable office wall partitions can be customized, including the size, color and finishes. We can produce the Operable wall partitions wall based on the difference demands of different client. The price is difference based on the different size and material, Welcome to contact us for more details.
FAQ
1. Q: Are you a manufacturer or trading company?
A: We are a famanufacturer, and this is our address: No.39-2, Nanwei Road, Hailong street, Longxi
Avenue, Liwan District, Guangdong Province, China.
2. Q: What is the price of the movable wall?
A: Our mobile wall system is customized, the cost is calculated by area, the thickness of different
walls and the price of different finishes are different. Therefore, we need you to provide us detailed
dimensions such as height, width and finish requirements. If possible, we also need your
layout drawings.
3. Q: Is the movable partition acoustic (soundproof)?
A: Yes, our movable wall system is soundproof. We have different acoustic material fillings and
various sound absorbing panels to achieve different acoustic ratings. For the 65 series we can
reach 45db, for the 80 type we can reach 48db, the 85 type can reach 50db, for the 100 type
we can reach 50db.
4. Q: How to install an active partition? Is it difficult to complete?
A: It is not difficult to install our active partitions. Our active partition is a hanging rail type moving wall
that does not require any ground track. Therefore the hanging rail structure will be very important. We
have very detailed drawings and videos showing how to install, so your employees just need to follow
them step by step.
5. Q: Do you provide sample?
A: Yes, and the sample is free, you just pay the express delivery fee is ok.
6. Q: What is your payment terms?
A : 30% - 50% of total amount by T/T as deposit when confirmed the order and balance paid by T/T
before loading container, or irrevocable L/C at sight.
7. Q : What is your warranty ? What do we do in case of problems?
A : 3 years quality warranty is provided, including frame unfading nor peel-off, hardware and
accessories working properly under correct operation.In case of our quality problem, we will provide
replacement by international courier. Immediate delivery of replacement parts with available in stock,
and if not stocking, the time should be depending on material ordering time which is normally 10-
15 days.
