Ebunge BG-65 Series Movable Partition Walls For Office / Movable Room Divider
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | EBUNGE |
| Model Number: | 65 MM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 square meter |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton paper packing ,MDF Batten cover all over the corner |
| Delivery Time: | 7-28 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 square meters per month |
|
Detail Information |
|||
| Features: | Movable, Sliding, Folding | Product Name: | Movable Partition Walls |
|---|---|---|---|
| Material: | MDF With Melamine | Color: | Customized |
| Function: | Soundproof Partition Wall Panels | Service: | ODM OEM |
| MOQ: | NO MOQ | Finish: | Melanimine |
| Package: | Standard Wood Case | Frame Material: | Aluminum Alloy Profile |
| Height: | 4000 MM | ||
| Highlight: | movable walls on wheels,movable partitions systems |
||
Product Description
Chinese suppliers Ebunge partition BG-65 series movable room divider movable wall partition for office
1) Movable wall interlocks male / female trapezoidal vertical aluminium profiles, for soundproof connection between elements.
2) Movable wall to ensure additional friction connection, shall be integrated with magnetic strip.
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
Ebunge partitions all apply hanging system.
These profiles are fitted with magnetic membrances which ensure positive interlocking of the panels. Once the wall panels have been adjusted for height and level, the roller stems are locked with a fail-safe mechanism to ensure that the panels will align perfectly every time the wall is set up. Pressure seals extend from the top and bottom of each panel exerting a closing pressure of 2kg provicling pravicling panel stability and excellent acoustic sealing.
Panel faces are suspened from a steel frame with just 1 or 2 points of contact. The edges of panel faces are slotted into aluminum profiles. This method of cladding the steel frame allows the panel faces to be acoustically separated from each other and thereby minimizes the transfer of sound waves through the system. Each panel has an extruded aluminum male profile to one vertical edge and a female profile to the other.
Key Feature & Benefits
1. Individual panels that can be stored away form maximum space utilisation.
2. Operable top and seals for effortless operation.
3. Isolated aluminum frame construction for enhanced acoustic.
4. No floor track ensuring obstruction free threhold.
5. Three panel sizes to accommodate a wide range of acoustic requirements.
6. Extensive range of surface finishes can be applied.
Packaging & Delivery
Selling Units:Single item
Single package size: 4000X1100X100 cm
Single gross weight:26.0 kg
Package Type:Carton package, MDF batten on four section sides ,foam board on both front face
Lead Time :
| Quantity(Square Meter) | 1 - 50 | 51 - 200 | 201 - 500 | >500 |
| Est. Time(days) | 7 | 18 | 28 |
To be negotiated |
About finish
Different surface use in different areas.Our main surface is mdf melamine, it can be more easy to clean.Also fabric and leather surface is very popular in conference room or banquet hall.And like dancing room or classroom,client prefer mirror surface.Also we can design surface pu leather with printing photos.If client prefer to paint color on panels, we suggest Mdf bare finish.If prefer to glue wallpaper, plywood surface is a good choice.
FAQ
1. What the Movable Partition Wall use for?
They are the creative way to add flexibility and functionality to your space.extensively applied to star hotels, meeting rooms, ballrooms, clubs, banquet hall, convention centers, multi-function halls, training rooms and other facilities.
2. Have your partition wall products come in standard sizes?
No, actually all of our movable partition wall sizes are supported customized. The panels move on the ceiling track with no floor track.
3. How long does it take to install a partition system?
We will provide a detailed schedule on receipt of the order and keep everything updated regularly on progress. The time depends very much on the site and anything which we try to meet wherever possible.
4. Can you give us an initial indication of the cost of a particular system?
Yes.we can. We would need more information and possibly a site visit and survey before confirming and exact price.
5. Do I need to have an architect or building contractor?
Usually we only offer the site supervision service.if you are already using another contractor for other work then we can work with them to ensure a smooth process.
6. Do I need to provide technical information or drawings?
Yes, we need. If you already have technical information or drawing then we can use them to build and install the selected
products.
7. Are your products guaranteed?
Yes,all of our products carry a full 3 Year guarantee,covering all parts and defects. We can also provide an extended warranty if require and the products are expected to last a lifetime.
