Sound Proof Partitions Folding Interior Door Partition Wall Movable Room Partition Wall Divider For Multi Function
Product Details:
| Place of Origin: | Guangzhou,China |
| Brand Name: | EBUNGE |
| Model Number: | Series 65 mm sliding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10pcs |
|---|---|
| Price: | 60-119 USD per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Product Name: | Folding Partition Walls | Material: | Aluminium And Mdf Board |
|---|---|---|---|
| Height: | Less Then 4 M | Width: | 500-1200 Mm |
| Thickness: | 65mm Aluminum Frame | Function: | Sliding Room Divider |
| Finish: | Melamine, Fabric, Leather, MDF Bare Finish | Warranty: | Sliding Partition Walls Warranty 3-5 Years |
| Highlight: | Movable Room Sound Proof Partitions,Folding Interior Door Partition Wall |
||
Product Description
Sound proof partitions folding interior door partition wall movable room partition wall divider for multi-function
Description:
1. Trackless suspension: there is no track on the floor, only track system hanging on the ceiling;
2. Stability and safety: stable and reliable after fixed, not easy to swing;
3. Sound insulation and environmental protection: sound insulation effect is good, and the maximum sound insulation coefficient can reach 53dB;
4. Heat insulation and energy saving: excellent heat insulation performance, according to different occupancy rates, the large space is divided into small space to reduce the air conditioning power consumption;
5. Efficient fire prevention: adopt efficient fire prevention materials and have good fire protection performance;
6. Beautiful and generous: any decoration on the surface can be unified with the interior decoration effect;
7. Flexible: partition board can be retracted and put freely, and push flexibly, a person can complete the whole process of partition;
8. Easy to collect: when parking the partition, the partition board can be hidden in the special storage cabinet, without affecting the overall appearance;
9. Widely used: it can be used in conference hall, exhibition hall, restaurant, high clean factory, office and any other big space.
Technical parameters:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Model 65mm movable wall are made of aluminum alloy frames and it’s thickness is 65mm. The aluminum is 6063-T6. Oxidation, electrophoresis and other processing methods can be adopted according to customers.
Model 65mm mobile partition belongs to the light partition, its operation easy and flexible. Each panel can be a single hanging and sliding with single wheel, partition panel can be 360 degrees rotation.Or suing two hanging wheels that can be a full range of sliding turn and can be pushed to any place.Sliding stable and smooth making dimensional change shows diversity.
Model 85mm mobile partition belongs to the best cost-effective partition, moderate weight make the operation convenient and flexible.Each panel can be a single hanging and sliding with single wheel, partition panel can be 360 degrees rotation.Or suing two hanging wheels that can be a full range of sliding turn and can be pushed to any place.Sliding stable and smooth making dimensional change shows diversity.
Model 100mm movable partition is high sound insulation,more heavy, sliding and operation stable. Each panel can be a single hanging and sliding with single wheel, partition panel can be 360 degrees rotation.Or suing two hanging wheels that can be a full range of sliding turn and can be pushed to any place.Sliding stable and smooth making dimensional change shows diversity. It’s the best choice of sound insulation requirements.
Acoustic performance:
Our Top Hung acoustic operable walls were designed specifically with the office refurbishment sector in mind. With sound attentions available from 37dB RW to 53 dB RW, there is no acoustic issue between rooms that the Top Hung Operable Wall cannot cater for.
Sound reduction dB ratings are often quoted from laboratory test results which are misleading in respect of final performance values. They are merely useful for initial specification purposes. Independent on-site tests as carried out by partners are recommended as in-situ results will differ from laboratory test certification and are therefore the only true guide to achievable sound attenuation.
