Noise Insulation Demountable Folding Sliding Wall Partition For Restaurant
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO 9001 |
| Model Number: | Model 100 sliding wall partition |
Payment & Shipping Terms:
| Minimum Order Quantity: | NO MOQ, small quantity welcome |
|---|---|
| Price: | $82-88 per square meter |
| Packaging Details: | Paper carton, outside with wooden box |
| Delivery Time: | 7-15 days |
| Payment Terms: | T/T, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Product Name: | Sliding Wall Partition | Service: | One Stop Service |
|---|---|---|---|
| Thickness: | 100 Mm | Max Height: | 6 Meters |
| Application: | Restaurant Partition Wall | Warranty: | 3 Years |
| Highlight: | Demountable Folding Sliding Wall Partition,100mm Thickness Sliding Wall Partition,6 Meters Height Sliding Wall Partition |
||
Product Description
Noise Insulation Demountable Folding Sliding Wall Partition for Restaurant
Sliding Wall Partitions for Restaurant Features
1. Sliding wall partitions for restaurant can separate the space speedy and conveniently.
2. Top hung system without the need for a floor track.
3. Sliding wall partition is made from high density aluminum frame, special made rubber, excellent sound insulation cotton and finish surface, etc.
4. Around the sliding wall partition for restaurant panel, there is sound insulation rubber, it can help to insulate the sound entering.
5.The sliding wall partition finished panel is hanging on the aluminum track, assembled with muti direction wheels.
We Offer
We ensure the Quick delivery and good quality guarantee.
Our company manufacture products according to buyer's dimension quantity,
drawing or other related requirements.
After sales service including:
Overseas service availabe,
Using top quality materials and components.
Maintenance contracts to ensure your valuable asset remains in full work order.
| TYPE | BG65 | BG85 | BG100 & BG125 |
| Panel suspension | Top hung only | ||
| Track system | Single or twin point | ||
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Panel height | Up to 4000mm,heights greater than 3000mm refer to our technical dept. | Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional. | |
| Max height | 4000mm | 6000mm | 17000mm |
| Panel width |
500 - 1200mm 1' 5/8" -- 4' |
500 - 1200mm 1' 5/8" -- 4' |
500 - 1200mm 1' 5/8" -- 4' |
| Surface material | 9mm | 9mm | 12mm |
| Vertical profiles | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional |
| Locking | Optional lock to passing doors | ||
| Passing doors | Single open in one panel or double open in two panel | ||
| Sound insulation | 22-32 dB Rw | 28-40 dB Rw | 40-55 dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx 30-48kg/sq M |
Sliding Wall Partition for Restaurant Detail
With the unique multi-layer panel system, our sliding wall partition for restaurant has excellent acoustic performance with a STC up to 22-55 dB.
Double PVC seals are mounted around the sliding wall partition for restaurant to provide the highest level of acoustic integrity. More importantly, this fit can also achieve the desired acoustic integrity between two nearby rooms.
The acoustic structure includes multi-layer board at the top and bottom of the sliding wall partition and the glass wool inside. The acoustic performance is up to 40 STC, and the fabric wrapped acoustic panel and perforated MDF panel can be used to reduce echo. The vinyl at all edges help to prolong life time and seal the noise.
These sliding wall partitions for restaurant will be provided in an end-folded configuration to meet a variety of parking requirements and the first panel can be provided as a standard access door.
The sliding wall partition for restaurant has aluminum profiles, and panels are available for a variety of surface treatments including painted, polished veneer or various standard or high pressure laminate. Fire rated finish panel is also available.
