Reduction Noise Theater Polyester Acoustic Diffuser Panels , Sound Absorption Board
Product Details:
| Place of Origin: | Guangdong,China |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Acoustic diffuser panel |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 Square Meter |
|---|---|
| Price: | 50-150 USD per square meter |
| Packaging Details: | Carton with Pallet |
| Delivery Time: | in 7 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters |
|
Detail Information |
|||
| Type: | Acoustic Panels | Model Number: | WDF |
|---|---|---|---|
| Acoustic Panel Type: | Diffuser Acoustic Panels | Core: | Cedar Wood |
| Size: | 600*600 Mm | Color: | Multi Color |
| Edge Treatment: | Square | Thickness: | 112 Mm |
| Highlight: | audio diffuser panel,ceiling diffuser panels |
||
Product Description
Fireproof Material Polyester Acoustic Diffuser Panel
Description:
Diffused acoustic panel used high density mold- proof, fireproof, environmental MDF,Poly-foam,Walnut wood as base material,processed by full automatic computer controlled equipment,can give good decoration &diffusion function,make the room sound energy distribution and eliminate echo.
Diffusion frequency:125-4KHz center spread around 1kHz frequency.
Advantages:
1.Excellent acoustic performance
2.Sound absorbing and noise reduction
3.Improving sound articulation
Features:
1.For more than the band's sound diffusion and reflection.
2.Can be hidden among the entire theater audio-visual room of Art and Design.
3.Must achieve synchronization installation and testing acoustic treatment.
4.To avoid acoustic problems coloration sound focusing and standing wave.
5.Environmental friendly with no smell.
6.Easy Installation.
Technical information:
| Product name | Sound Diffuser Foam Acoustic Panel |
| material | Solid wood |
| Size | 600*600mm |
| Thickness | 100mm |
| Finish | Melamine, veneer, wood grain PVC, PU paint finish |
| Paint | PVC, PU painting |
| Density | 680kg/m3 |
| Diffuser frequency | 125~4000hz |
| Fireproof grade | B1 |
| Pre-production grade | E1 |
| Installation | Wood frame |
Structure:
It use high density board to manufacture, paint finishes ,with holes on back side and use black acoustic tissue which has fire rated and sound-absorption function.
Spread principle :
QRD spread principle is a change of the depth of the parallel "Algae into "composition, when sound waves 135 degrees to the level of the incident QRD position, it can in 30 degrees to 150 degrees
in equal between the intensity of sound will reflect out.
Absorption:
QRD reflection is difference according to different woodiness and designs have different characterless of absorption ,we can design out according to the different requirements of customers provide
diffusion system number and the absorption.
Eco-friendly:
Eco-sound Wooden Sound diffuses acoustic panel its material original wood, natural texture, will not broke under the huge impact of high elasticity.
Wooden Sound diffuses acoustic panel is Green products, asbestos-free, non-toxic and tasteless gas under extreme temperature, protecting the ozone layer, non-irritant and recyclable.
Physical property:
Eco-sound Wooden Sound diffuses acoustic panel is sound solution board, thermal-insulating, elastic, wear-resistant, impact-resistant, hard to tear.
Decorative property :
Eco-sound Wooden Sound diffuses acoustic panel has excellent decorative effect. We offer you more than 20 kinds different type for choice.
